Skf Bearing Number And Size Chart Pdf

SKF rolling bearing catalogue is divided into two main sections: a technical section and a product section. The technical section describes how to select and apply SKF rolling bearings and covers eight main topics marked with printed tabs from A to H. The product section is divided into chapters by product type. Each chapter contains specific information about the SKF bearing type and its optional variants and product tables. Each product chapter is marked by cut tabs with an easily identifiable icon.


A quick way to access detailed product data is via a product table number or SKF-bearing size chart. Product table numbers are listed at the front of the product catalogue, at the beginning of each product chapter, and in the product index at the back of the catalogue.


SKF Rolling Bearings Catalogue


This catalogue contains the standard assortment of SKF rolling bearings typically used in industrial applications. To provide the highest quality and customer service, these products are available worldwide through SKF sales channels. For information about lead times and deliveries, contact your local SKF representative or SKF Authorized Distributor.

The data in this catalogue reflect SKF’s state-of-the-art technology and production capabilities as of 2012. The data contained within may differ from earlier catalogues because of redesign, technological developments, or revised calculation methods. SKF reserves the right to continually improve its products concerning materials, design, and manufacturing methods driven by technological developments.

This catalogue contains detailed information about standard SKF rolling bearings, several specially engineered products and bearing accessories. Engineered products include motor encoder units, which can measure the speed and direction of rotation, polymer bear­ings and rolling bearings designed to fulfil additional requirements, such as:

• extreme temperatures
• electrical insulation
• dry lubrication
• insufficient lubrication
• rapid speed changes
• high vibration levels
• oscillating movements


The first section, which contains general tech­medical information, is designed to help the reader select the best, most effective products for a particular application. In this section, bearing service life, speed capabilities, fric­on, general design considerations and lubri­cation is discussed in detail. Installation and maintenance information is also included. More practical information about mounting and maintenance is provided in the SKF bearing maintenance handbook (ISBN 978­91­978966­4­1).

Find product details quickly

A quick way to access detailed product data is via a product table number. Product table numbers are listed in the table of contents at the front of the catalogue, in the table of con­ tents at the start of each product chapter and in the product index at the back of the catalogue.

Identify products

Product designations for SKF rolling bearings typically contain information about the bear­ing and additional features. To specify an SKF bearing or to find more information about it, there are three options:

• Product Index
The product index at the end of the cata­Logue lists series designations and relates them to the bearing type and guides the reader to the relevant product chapter and product table.

• Designation charts
Product designations in each product chap­ there are located on the pages preceding the product tables. These charts identify com­ only used designation prefixes and suffixes.

• Text index
The text index at the end of the catalogue contains designation suffixes in alphabetical order. They are printed boldly for quick browsing.




The latest developments




Compared to the previous catalogue, the main content updates include the addition of Y­bearings and needle roller bearings and the following featured products: SKF Energy Efficient bearings.
To meet the ever­increasing demand to reduce energy use, SKF has developed the SKF Energy Efficient (E2) performance class of rolling bearings. SKF E2 bearings are charac­terized by a frictional moment in the bearing SKF Energy Efficient bearings are identified by the designation prefix E2.


SKF bearings catalogue pdf


  • Principles of SKF bearing selection and application

    • Bearing basics

    • Selecting bearing size

    • Friction

    • Speeds

    • Bearing specifics

    • Design considerations

    • Lubrication

    • Mounting, dismounting and bearing care

  • SKF bearing categories

    • Deep groove ball bearings

    • Y-bearings (insert bearings)

    • Angular contact ball bearings

    • Self-aligning ball bearings

    • Cylindrical roller bearings

    • Needle roller bearings

    • Tapered roller bearings

    • Spherical roller bearings

    • CARB toroidal roller bearings

    • Thrust ball bearings

    • Cylindrical roller thrust bearings

    • Needle roller thrust bearings

    • Spherical roller thrust bearings

    • Track runner bearings

    • Engineered products

    • Bearing accessories


SKF bearings unit conversions

Quantity   UnitConversion
Lengthinch1 mm0.03937 in.1 in.25,40 mm
foot1 m3.281 ft.1 ft.0,3048 m
yard1 m1.094 yd.1 yd.0,9144 m
mile1 km0.6214 mi.1 mi.1,609 km
Areasquare inch1 mm20.00155 sq­in1 sq­in645,16 mm2
square foot1 m210.76 sq­ft1 sq­ft0,0929 m2
 Volumecubic inch1 cm30.061 cu-in1 cu-in16,387 cm3
cubic foot1 m335 cu-ft1 cu-ft0,02832 m3
imperial gallon1 l0.22 gallon1 gallon4,5461 l
US gallon1 l0.2642 US gallon1 US gallon3,7854 l
Speed,
velocity
foot per second mile per hour1 m/s3.28 ft/s1 ft/s0,30480 m/s
1 km/h0.6214 mph1 mph1,609 km/h
Massounce1 g0.03527 oz.1 oz.28,350 g
pound1 kg2.205 lb.1 lb.0,45359 kg
short ton1 tonne1.1023 short ton1 short ton0,90719 tonne
long ton1 tonne0.9842 long ton1 long ton1,0161 tonne
Densitypound per cubic inch1 g/cm30.0361 lb/cu-in1 lb/cu-in27,680 g/cm3
Forcepound-force1 N0.225 lbf.1 lbf.4,4482 N
Pressure,
stress
pounds per square inch1 MPa145 psi1 psi6,8948 ¥ 103 Pa
1 N/mm2145 psi

1 bar14.5 psi1 psi0,068948 bar
Momentpound-force inch1 Nm8.85 lbf-in1 lbf-in0,113 Nm
Powerfoot-pound per second1 W0.7376 ft-lbf/s1 ft-lbf/s1,3558 W
horsepower1 kW1.36 hp1 hp0,736 kW
TemperaturedegreeCelsiustC = 0.555 (tF – 32)FahrenheittF = 1,8 tC + 32
